Automated verification of calculation grades
Tower upgrades: industrialise your structural calculations
Optimise structural calculations to enable multi-tenant towers.
Time Saving
Optimise your calculation note processes
Collecting and checking input data for the creation of structural calculation notes is still a very manual process. Some data is missing or inconsistent, and engineers have to compare many sources. Formats vary from one partner to another, and the level of detail is not the same, which creates delays and extra cost.
With Kontrol, design offices and tower manufacturers finally have a way to process multiple documents in minutes and bring together all the data needed to produce structural calculation notes.
Transform and make it more reliable
Streamlined data collection
Get your input data ready for tower upgrade projects with Kontrol. Structural calculation notes, drawings, as-built files and technical sheets are processed in bulk, so your studies start from an AI-structured dataset instead of hours spent digging through scattered documents.
Automatically extract the data you need.
Lattice towers, monopoles, guyed structures: each tower type comes with its own set of parameters. With kontrol, analyse all documents and identify the information you are looking for instantly:
- structural elements, with associated measurements and coefficients;
- all installed equipment, with their main specs;
- More than 150 data points available, such as heights, sections and configurations
The extraction is automated: data from heterogeneous documents is transformed into a structured dataset you can reuse over time.
See data quality at a glance
Save hours of structural engineer time by immediately highlighting:
- available data points;
- contradictory or inconsistent information;
- missing values, via a system of alerts.
Export the extracted data in the most convenient format for you (.csv, .json, etc.) and inject it into your calculation tools as input data.
AI as an assistant for structural experts
The AI developed by kwarto is designed to keep information transparent:
- compare information coming from different documents;
- access the most probable hypotheses suggested by the AI when data is missing or conflicting.
Cut down time spent on collection and checks, and focus on producing and validating sound calculations.
Secure your structural assessments
Define and control your own standards
Formalise your requirements for input data: required level of detail, mandatory fields, and the information needed to validate a study.
These standards are then used by Kontrol as control rules: each time a tower is upgraded, the solution checks whether the calculation note and associated documents meet your specifications.
Field data
Complete missing data with field teams
Even after careful analysis of many documents, some pieces of information may still be missing or uncertain. With the kwarto mobile app, you can collect data directly on site:
- create specific forms for missing data;
- technicians fill them in during a technical visit;
- existing data can be confirmed or corrected during the same visit.
1. Feed your calculations with up-to-date data
Information collected in the field is synchronised with Kontrol: the central database is enriched and updated, future calculation notes can rely on more complete input data, your structural calculation tools benefit from current values. Office and field contribute to the same reference dataset.
2. Set up an effective end-to-end process
Kontrol allows you to set up an industrialized process where each site visit is calibrated to retrieve the correct data:
Kontrol automatic analysis of the documents you already have
Mobile app kwarto (or drone): on-site collection of missing or inconsistent data
Kontrol : immediate update of your dataset
Design office or pylons: production of the structural calculation note
Your site visits are particularly targeted, saving you valuable time and ensuring the reliability of your analyses.
From PDF to usable data
Turn scattered tower files into a structured data model
Kontrol turns scattered calculation notes and drawings into a central, technical database that you can query and connect to your existing tools.
Structured data replaces scattered folders, giving you an increasingly precise view of your infrastructure and a solid, consistent technical foundation for your decisions.
Move from PDFs and spreadsheets to a usable database
Instead of multiple documents, work with a complete technical database:
- access information any time;
- exports are available as flat files (.csv, .json, etc.) to feed your tools;
- links are preserved between structured data and the original documents.
Your documentation becomes an evolutive, searchable, collaborative resource.
Build deeper knowledge of your own towers
Each new calculation note contributes to enhance your baseline:
- structured data feeds the central database;
- detected discrepancies are corrected;
- you broaden your portfolio's knowledge over time.
Control over your infrastructure is built on a consolidated technical foundation.
Integrate Kontrol into your information systems
Connect Kontrol to your own applications (calculation tools, asset registers, reporting, etc.). Our solution is fully available via API, so you can assimilate enriched technical data to your existing systems, without re-keing.
Key benefits
Benefits for all stakeholders in tower upgrade projects
Design offices and engineering firms
Save time working on structural studies
Improved reliably of input data for calculations
Traceability of recommendations issued in calculation notes
Increased efficiency and smoother interactions with towerCos and MNOs
Tower manufacturers
Better use of existing documentation on the installed tower base
Cut the time spent on data collection by highly qualified resources
Meet requests from towerCo clients faster and more efficiently
Get a structured technical data ready to support future work and projects
